5G BOAT
5G / LTEMarine cellular connectivity
TECH SPECSAcheter
Chargement du prix et du stock…
Overview
| Product type | Marine 5G / LTE CPE |
|---|---|
| Mobile networks | 5G NR SA / NSA · LTE |
| 5G SA maximum rate | 2.4 Gbps downlink · 900 Mbps uplink |
| 5G NSA maximum rate | 3.4 Gbps downlink · 550 Mbps uplink |
| LTE maximum rate | 1.6 Gbps downlink · 200 Mbps uplink |
| Ethernet | 1× 2.5 GbE |
| SIM | 2 SIM slots |
| Weather protection | IP67 |
Cellular & Antenna
| Cellular MIMO | Up to 4×4 downlink · 2×2 uplink, band dependent |
|---|---|
| Antenna frequency | 617–3,800 MHz |
| 5G SA / NSA bands | n1 / n3 / n5 / n7 / n8 / n20 / n28 / n38 / n40 / n41 / n71 / n75 / n76 / n77 / n78 |
| LTE FDD bands | B1 / B3 / B5 / B7 / B8 / B20 / B28 / B32 / B71 |
| LTE TDD bands | B38 / B40 / B41 / B42 / B43 |
Hardware
| USB | 1× Type-C |
|---|---|
| Reset | Reset button |
| WiFi | Via external WiFi router |
| Power | 802.3af/at PoE |
| Maximum consumption | <20 W |
| Dimensions | Ø267 × 493 mm |
| Weight | 5 kg |
| Color | White |
| Mounting | Pole mount; customizable |
Cellular rates are theoretical maxima. Actual performance depends on network coverage, operator configuration, antenna alignment and installation conditions. Band availability depends on the installed cellular module and region.
STANDARD PACKAGE
In the box
Package configuration for 5G BOAT.
Package contents available on request.
Confirm the supplied mounting and power accessories for your configuration.
Request package detailsPRODUCT PHOTOGRAPHY
5G BOAT, in detail.
Explore the original product views.
INSTALLATION ESSENTIALS
Complete the installation.
Connection and mounting requirements for 5G BOAT.
Mobile service
An active SIM and a compatible LTE / 5G data plan.
Check your deployment configurationMounting support
Use suitable outdoor mounting hardware for the deployment.
Check your deployment configurationPower input
802.3af/at PoE
Check your deployment configurationINSTALLATION NOTES
Install. Connect. Configure.
Deployment checklist for 5G BOAT.
Prepare the SIM
With power disconnected, insert an active SIM for a compatible mobile network.
Mount the CPE
Secure the unit with the appropriate mounting hardware. Optimize its location for cellular reception.
Connect power and Ethernet
Connect the documented PoE supply and Ethernet network. Seal the outdoor cable entry.
Configure cellular access
Set the operator APN as required and verify network registration, signal quality and data connectivity.
5G BOAT
