LITE E16
WiFi 7Connect cameras with a compact radio
TECH SPECSAcheter
Chargement du prix et du stock…
Overview
| Primary application | Remote camera / camera cluster |
|---|---|
| Wireless technology | WiFi 7 |
| Spatial Diversity | 2x2 MIMO |
| Network interfaces | 2× 2.5 GbE |
Radio & Antenna
| Antenna | 16 dBi directional |
|---|---|
| Channel width | 20 / 40 / 80 / 160 / 320 MHz |
| Operating frequency | 5.18–6.415 GHz or 5.925–7.125 GHz, according to radio version |
| Maximum transmit power | 29 dBm |
| Antenna frequency range | 5.15–7.125 GHz |
| Polarization | Dual linear |
| Antenna beamwidth | E-plane 40° · H-plane 18° |
Hardware
| Weight | 0.8 kg |
|---|---|
| Dimensions | 180 × 105 × 31 mm |
| Outdoor construction | IP67 enclosure |
| Operating temperature | −35 to +50°C |
| Power | PoE 22–56 V / DC 12–48 V |
| Variants | 5 GHz or 6 GHz radio configuration |
| Maximum consumption | <15 W |
| Mounting | Compact pole installation |
| Processor | Qualcomm quad-core A53 · 1.1 GHz |
| Surge suppression | 8 kV |
Networking & Management
| Wireless operating modes | AP WDS · Client WDS |
|---|---|
| Network modes | Bridge · Router |
| Firewall | Port forwarding · DMZ · ACL filtering |
| Wireless security | WPA / WPA2-PSK · WPA2-PSK / WPA3-SAE · WPA3-SAE |
| VLAN | IEEE 802.1Q with 802.1p priority |
| DHCP | Server · Client |
| Management | HTTP / HTTPS · SNMPv1/v2/v3 · TR-069 |
| QoS | Three priority levels; DSCP, CoS, VLAN, IP and MAC classification |
| ARQ | Supported |
PHY rates are theoretical. Actual throughput and range depend on radio configuration and operating conditions. Available frequencies, channel widths and transmit power depend on the country of operation.
STANDARD PACKAGE
In the box
Package configuration for LITE E16.
Package contents available on request.
Confirm the supplied mounting and power accessories for your configuration.
Request package detailsPRODUCT PHOTOGRAPHY
LITE E16, in detail.
Explore the original product views.
INSTALLATION ESSENTIALS
Complete the installation.
Connection and mounting requirements for LITE E16.
Mounting support
Compact pole installation
Check your deployment configurationOutdoor Ethernet
Use shielded cabling and weather-sealed connections.
Check your deployment configurationPower supply
PoE 22–56 V / DC 12–48 V
Check your deployment configurationINSTALLATION NOTES
Install. Connect. Configure.
Deployment checklist for LITE E16.
Mount and align
Choose a mounting position with a clear line of sight. Secure the radio and align the directional antenna with the remote site.
Connect the network
Connect an outdoor-rated shielded Ethernet cable and seal exposed connectors.
Connect power
Use the power method listed in the hardware specifications and verify the device label before energizing.
Configure and verify
Set the country, radio mode, frequency and wireless security. Verify alignment and link performance.
