O3B-6P-R
AntennaTri-band six-port omnidirectional antenna
TECH SPECSAcheter
Chargement du prix et du stock…
Overview
| Product type | Tri-band omnidirectional antenna |
|---|---|
| Frequency range | 2,400–2,485 MHz · 5,150–5,850 MHz · 5,900–7,125 MHz |
| Gain | 6 dBi · 8 dBi · 8 dBi |
| RF ports | 6 |
| Connector options | 6× RP-SMA or RP-TNC |
Electrical
| Horizontal beamwidth | 360° |
|---|---|
| Vertical beamwidth | 55° at 2.4 GHz · 30° at 5 GHz · 30° at 6 GHz |
| Polarization | Linear · Vertical |
| Port isolation | >20 dB |
| VSWR | <2.0 on all bands |
| Impedance | 50 Ω |
| Maximum power per port | 50 W |
Hardware
| Lightning protection | DC ground |
|---|---|
| Dimensions | Ø180 × 200 mm |
| Weight | 1.5 kg |
| Cable type | RG402 |
| Color | White |
| Radome material | ABS |
| Mounting | Pole · 30–50 mm diameter |
| Operating temperature | −40 to +70 °C |
Select an antenna and RF connector configuration compatible with the radio frequency bands, connector type and port count.
